Huawei BMS LUNA2000-5KW-C0 power modul
Modular system - charge control module
Lithium-iron-phosphate cell technology
10 year warranty
Passive cooling
| Značka: |
|
| Jednotka: | pcs |
| Kód: | ESS-HUA-LUNA2000-5KW-C0-BMS |
| Model: | LUNA2000-5KW-C0 |
| Záruka: | 10 rok |
| Výkon: | 5 kW |
The Huawei LUNA2000-5kW-C0 is a power control module of Huawei's home battery system. The LUNA2000 batteries are made with lithium iron phosphate cells and can be stacked up to three high for a maximum storage capacity of 15kWh per stack. However, the system can be expanded with a second stack for a total capacity of up to 30kWh with two stacks in parallel.
DC-DC connection
Expandable - each battery has its own optimiser, connect batteries with different demands
Battery module - 5 kWh capacity per module
Invereter connectable with 2 charge controllers in same time
Charge controller connectable with 3 battery modules
| Performance | |
| Power module | LUNA2000-5KW-C0 |
| Number of power modules | 1 |
| Battery module | LUNA2000-5-E0 |
| Battery module energy | 5kWh |
| Number of battery Modules | 1 |
| Battery usable energy | 5 kWh |
| Max. output power | 2.5kW |
| Peak output power | 3.5 kW, 10 s |
| Nominal voltage (single phase system) | 360V |
| Operating voltage range (single phase system) | 350-560V |
| Nominal voltage (three phase system) | 600V |
| Operating voltage range (three phase system) | 600 – 980 V |
| Communication | |
| Display | SOC status indicator, LED indicator |
| Communication | RS485 / CAN (only for parallel operation) |
| General Specification | |
| Dimension (W*D*H) | 670 * 150 * 600 mm (26.4 * 5.9 * 23.6 inch) |
| Weight (Floor stand toolkit included) | 63.8 kg (140.7 lb) |
| Power module dimension (W*D*H) | 670 * 150 * 240 mm (26.4 * 5.9 * 9.4 inch) |
| Power module weight | 12 kg (26.5 lb) |
| Battery module dimension (W*D*H) | 670 * 150 * 360 mm (26.4 * 5.9 * 14.0 inch) |
| Battery module weight | 50 kg (110.2 lb) |
| Installation | Floor stand (standard), Wall mount (optional) |
| Operating temperature | -10°C~ + 55°C (14°F~131°F) |
| Relative humidity | 5%~95% |
| Cooling | Natural convection |
| Protection rating | IP 65 |
| Noise emission | <29 dB |
| Cell technology | Lithium-iron phosphate (LiFePO4) |
| Warranty | Max. 2 systems in parallel operation |
| Compatible inverters | SUN2000L-2/3/3.68/4/4.6/5KTL 4,SUN2000-2/3/3.68/4/4.6/5/6KTL-L1,SUN2000-3/4/5/6/8/10KTL-M0 4, SUN2000-3/4/5/6/8/10KTL-M1 |
| Standard Compliance (more available upon request) | |
| Certificates | CE, RCM, CEC, VDE2510-50, IEC62619, IEC 60730, UN38.3 |
| Ordering and Deliverable Part | |
| Product ordering model | LUNA2000-5KW-C0, LUNA2000-5-E0, LUNA2000 Wall Mounting Bracket |
