Deye BOS-A High Voltage Battery Cluster Control Box

Deye BOS-A High Voltage Battery Cluster Control Box

The Deye BOS-A High Voltage Battery Cluster Control Box (BOS-A-PDU-2) is a control and distribution unit designed forhigh-voltage energy storage systems, providing centralized control of BOS-A battery clusters. The module ensures communication between batteries, power distribution, and safe system operation, making it a key component of high-voltage BESS systems.

Control of high-voltage battery clusters

The BOS-A-PDU-2 control unit is the central controller of BOS-A energy storagesystems, which monitors the operation of battery clusters and coordinates charging and discharging processes. The system continuously monitors operating parameters, ensuring stable and safe energy storage.

The control unit optimizes energy distribution among the battery modules and ensures seamless cooperation with the inverter.

Integrated BMS and Energy Distribution

The BOS-A cluster control box includes integrated BMS functions that protect the batteries against over-discharge, overcharge, and overcurrent. The system is capable of managing balancing and energy distribution among high-voltage battery clusters.

The rated charge and discharge current is 100 A, ensuring optimized operation for industrial energy storage systems.

High-Voltage Operation and System Integration

The control unit operates within a DC operating voltage range of 235.2–306.6 V, making it suitable for high-voltage energy storage systems. The system ensures communication and energy flow between the battery clusters and the inverter.

This enables the system to be integrated into industrial solar power systems and complex energy management solutions.

Compact design and easy installation

The BOS-A-PDU-2 is a compact control unit that can be easily integrated into rack or energy storage cabinet systems. Its robust mechanical design and standard connections facilitate installation and maintenance.

The system is designed for indoor installation (IP20), ensuring reliable operation in a protected environment.

SOLARKIT Reviews

The Deye BOS-A High Voltage Battery Cluster Control Box is a key component in BOS-A energy storage systems. The combination of control and distribution functions ensures the stable operation of battery clusters and efficient energy management of the system.

Recommended for those building high-voltage energy storage systems who are looking for a reliable, scalable control solution.
