Solax X3-EPS Parallel Box G2 60 kW

Prijava Za dodajanje v košarico se morate prijaviti!

X3-PBOX-60KW-G2 Datasheet

X3-EPS Parallel Box G2.pdf

Prenesi

GRID (INVERTER)
Grid connection	Three Phase
Rated voltage	220/380V,230/400V,240/415V
AC frequency	50/60Hz
AC output voltage range	(198~253)/(342~440)V
Maximum grid input current	87A
EPS (INVERTER)
Rated voltage	230/400VA
EPS frequency	50/60Hz
Compatible inverter	≤6
Maximum EPS input current per channel	21.7A
Maximum EPS input current	87A
LOAD (BACKUP)
Load connection	Single Phase/Three Phase
Rated voltage	220/380V,230/400V,240/415V
AC frequency	50/60Hz
Maximum apparent power	60kVA
Maximum output current	87A
Switchover time	<10s
GENERAL SPECIFICATION
Operating temperature range	-25°C to +40°C (-13°F to +104°F)
Relative humidity range	0~100 (condensing)
Dimensions (W × H × D)	492 x 478 x 183 mm (19.4 x 18.8 x 7.2 inch)
Weight	17kg
Degree of protection	IP65
